Turbo   Racing


GT3782R - 759361-0010 Turbo Kits

GT37 759361-0010 turbine mapGT3782R turbo
GT37 759361-0010 compressor map

Horsepower 350 HP
Torque 880 N·m

  • Dodge Cummins (2002.5 - 2007.5)
  • Ram 2500 & 3500 Cummins Diesel.
  • 2002.5 - 2007.5 Cummins Engine.
  • The GT3782R dual ball-bearing turbo.
  • A Garrett exclusive ball bearing cartridge for unbeatable response, efficiency, and durability. Elimination of the thrust bearing eliminates Failures at elevated boost levels.
  • The upgrade results in lower intake and exhaust gas temperatures as well as reduced backpressure for more efficient air flow.
  • Water-cooled center section with a patented dual ball-bearing center section results in higher durability and longer turbo life.
  • Oil inlet fitting features a built in restrictor for worry-free operation.
  • High flow compressor wheels move air quickly and powerfully.

Installation Instructions (405 Kb)

GT3782R COMPRESSOR TURBINE
Turbo CHRA Inducer Exducer Trim A/R Wh Dia Trim A/R Type
759361-0010 N/A - mm 82.0 mm - - - mm 78 0.89 Wastegated

ACCESORIES

COMPRESSOR HOUSING

Inlet
Part Number Description
not available Hose
not available T-bolt band
Outlet
Part Number Description
not available Hose
not available T-bolt band

TURBINE HOUSING

Inlet
Part Number Description
409039-0000 Gasket
219016 Flange
Outlet
Part Number Description
not available Gasket
not available Flange

BEARING HOUSING

Inlet
Part Number Description
not available O ring
Outlet
Part Number Description
210060 Gasket




Updated on July 03, 2011
